Omron F3SG-2RE0430P30, F3SG-RE Series Light Curtain, Sender & Receiver, 20 Beam(s), 30mm Resolution

Part Number : F3SG-2RE0430P30

Availability: Sold out

Detailed Description
Specifications

Omron F3SG-RE Series Light Curtain, 30mm Beam Resolution, 24V DC Supply Voltage - F3SG-2RE0430P30

This light curtain is a crucial safety device that enhances protection for personnel and machinery in industrial settings. Its design promotes safety by effectively preventing accidental contact with moving parts, contributing to a safer workplace. It is suitable for a range of applications, and its robust construction ensures reliable performance in demanding conditions.

Features & Benefits

• Compact design facilitates space-efficient installations
• Rapid response time improves safety during operations
• Powered by a 24V DC supply, allowing for flexible integration
• Simple installation with M12 pigtail Smartclick connector
• SIL 3 certification provides a high level of safety integrity
• Easily adjustable after installation for added convenience

Applications

• Protects against hazards from moving machinery components
• Integrated into automated assembly lines for personnel safety
• Used in robotics to avert accidental injuries
• Enhances safety measures in material handling operations

What is the maximum operating distance for safe functions?

The maximum operating distance is 20m, providing sufficient coverage for various setups.

What type of connection is used for wiring?

It utilises an M12 pigtail Smartclick connector for easy wiring.

Can it operate in different environmental conditions?

Yes, it functions effectively within a temperature range of -10 to 55°C.

Is cascading multiple units possible?

Yes, cascading is supported, allowing expansion of safety areas with multiple units.

What maintenance is necessary to ensure optimal performance?

Regular checks for damage and keeping sensor areas clean will help maintain peak functionality.

Brand	Omron
Series	F3SG-RE
Beam Resolution	30mm
Component Type	Receiver, Sender
Safety Type	2
PL EN ISO 13849-1	c
Number of Beams	20
Protective Height	430mm
Minimum Scanning Distance	0.3m
Maximum Scanning Distance	20m
Maximum Response Time	125 (OFF to ON Not Synchronized) ms, 25 (OFF to ON Synchronized) ms, 5 (ON to OFF) ms
Length	35mm
Supply Voltage	24 V dc
Height	430mm
Width	35mm
Terminal Type	4-Pin M12 Connector
Application	Arm, Finger, Hand
Features	Downsized, Easy Adjustment after Mounting, Ensuring Safe Restart, No Torque Control Required, Protected with Protection Cover, Quick Troubleshooting, Reducing Stops Due to Mutual Interference, Reliable Even in Harsh Environment, Robust & Compact Design, Slim Housing, Smart Muting Actuator, Used in Global & Harsh Environment
Dimensions	35 x 35 x 430 mm
