Omron G2RV-ST500 48VAC/DC, G2RV-ST Series Electromechanical Interface Relay, DIN Rail Mount, 48V ac/dc Coil, SPDT, 1-Pole, 6A Load

Part Number : G2RV-ST500 48VAC/DC

Availability: Sold out

Detailed Description
Specifications

Omron G2RV-ST Series Electromechanical Interface Relay, 100 MΩ Control Resistance, 5.4 mA Input Current - G2RV-ST500 AC/DC48

This Omron product is a DIN rail-mounted electromechanical interface relay. It features a 48V AC/DC coil, SPDT configuration, and a load current of 6A.

Features & Benefits

• Easy installation and organization of multiple relays on a standard DIN rail
• SPDT configuration provides flexibility to switch between two different circuits
• Handles higher current loads of 6A without overheating

Applications

• Reliable control of motor-driven equipment in industrial automation and manufacturing processes
• Manages lighting circuits in buildings, warehouses, or outdoor areas
• Suitable for heating, ventilation, and air conditioning (HVAC) systems

What is the coil voltage of this relay?

The coil voltage is 48V AC/DC.

Can I use this relay for motor control applications?

Yes, it’s suitable for motor control tasks such as switching pumps, fans, or conveyor belts.

What load current can this relay handle?

It can handle a load current of 6A.

Brand	Omron
Coil Voltage	48V ac/dc
Contact Configuration	SPDT
Mounting Type	DIN Rail
Number of Poles	1
Series	G2RV-ST
Load Current Rating	6A
Load Voltage Rating	250V ac
Minimum Input Voltage	43.2V
Maximum Input Voltage	52.8V
Terminal Type	Push In
Switching Voltage	440V ac
Depth	6.2mm
Height	90mm
Length	88mm
Contact Material	Ag Alloy
Input Current	5.4mA
Turn Off Time	20 (For DC)/40(For AC)ms
Operating Temperature Range	-40 → 55°C
Life	70000 cycles
