OMRON G6BK-1114P-US DC24 | PCB Mount Latching Power Relay | 24 V DC Coil, 5 A, SPST

Name: OMRON G6BK-1114P-US DC24 | PCB Mount Latching Power Relay | 24 V DC Coil, 5 A, SPST
Brand: OMRON
SKU: G6BK-1114P-US DC24
Availability: InStock

Part Number : G6BK-1114P-US DC24

With its 24 V DC coil, OMRON G6BK-1114P-US DC24 is an SPST PCB-mount latching power relay with a 5 A switching current rating. Coil resistance is listed as 2.06 kΩ, and contacts handle up to 380 V AC or 125 V DC.

SPST contact configuration
Max switching power: 1.25 kVA AC / 150 W DC
Contact material: silver
Operating temperature: -25 to +70 °C
Dimensions (L x D x H): 21 x 10 x 10 mm
Terminal type: through hole

Availability: low stock

Detailed Description
Specifications
Downloads

G6BK Latching

Double winding latching
Fully sealed
Switching Voltage: 30Vdc; 250Vac
Mechanical Life: 50 x 10⁶
Contact Resistance: 30mΩ
Contact Material: AgCdO
H11, W20, D10mm

Approvals

UL recognised; CSA certified

Approvals

UL; CSA

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	SPST
Mounting Type	PCB Mount
Switching Current	5A
Latching	Yes
Terminal Type	Through Hole
Maximum Switching Voltage AC	380V ac
Maximum Switching Voltage DC	125V dc
Length	21mm
Coil Resistance	2.06 kΩ
Depth	10mm
Minimum Operating Temperature	-25°C
Height	10mm
Contact Material	Silver
Maximum Operating Temperature	+70°C
Maximum Switching Power DC	150 W
Maximum Switching Power AC	1.25 kVA
Application	Power
Dimensions	21 x 10 x 10mm
