Name: Omron H5CX-AD-N, H5CX Series Panel Mount Timer Relay, 12 → 24V ac/dc, 1-Contact, 0.001 s → 9999h
Brand: OMRON
SKU: H5CX-AD-N
Availability: OutOfStock

Omron H5CX-AD-N, H5CX Series Panel Mount Timer Relay, 12 → 24V ac/dc, 1-Contact, 0.001 s → 9999h

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron H5CX-AD-N, H5CX Series Panel Mount Timer Relay, 12 → 24V ac/dc, 1-Contact, 0.001 s → 9999h

Part Number : H5CX-AD-N

Availability: Sold out

Detailed Description
Specifications

Omron H5CX Series Timer Relay, 0.005A Maximum Current, Panel Mount - H5CX-AD-N

This timer relay by Omron is a solid-state, ultra-compact equipment with high precision and a wide range of programming features. It offers precise time delay functionality, suitable for various industries. The timer relay ensures accurate timing for various applications, making it a reliable choice for various projects.

Features & Benefits

• Panel mounting type for easy installation
• Time range of 0.001s - 9999h for wide range of control
• SPDT switch configuration for efficient operation
• Screw terminal type for convenient setup

Applications

• Automation systems
• Control panels
• Lighting systems
• Motor controls

Can it be used for automation systems?

Yes, this timer relay by Omron is suitable for various automation applications.

Will it work with control panels?

Yes, this SPDT relay is designed to work seamlessly with control panels.

Is it suitable for motor controls?

Yes, the timer relay is reliable for motor controls to provide accurate timing functions.

Brand	Omron
Supply Voltage	12 → 24V ac/dc
Mounting Type	Panel Mount
Mode of Operation	Cumulative, Interval, ON/OFF Duty Adjustable Flicker, Power ON Delay, Repeat Cycle, Signal OFF Delay, Signal ON Delay, Stopwatch
Time Range	0.001 s → 9999h
Number of Contacts	1
Number of Timer Functions	Multi Function
Time Increment	Hours, Seconds
Maximum Current	0.005A
Maximum Voltage	24V dc
Switch Configuration	SPDT
Terminal Type	Screw
Power Supply	External
Width	48mm
Minimum Voltage	12V dc
Depth	63.7mm
Length	48mm
Maximum Operating Temperature	+55°C
Series	H5CX
