OMRON K3HB-XAA 100-240VAC | Digital Panel Multi-Function Meter | Current, Voltage, LCD, 100 mm Depth

Name: OMRON K3HB-XAA 100-240VAC | Digital Panel Multi-Function Meter | Current, Voltage, LCD, 100 mm Depth
Brand: OMRON
SKU: K3HB-XAA 100-240VAC
Availability: InStock

Part Number : K3HB-XAA 100-240VAC

The OMRON K3HB-XAA 100-240VAC is an LCD digital panel meter for current and voltage, with a 45 x 92 mm cutout and 100 mm depth.

Properties measured: current, voltage
Display: LCD
Cutout: 45 x 92 mm
Depth: 100 mm
Operating temperature: -10 to +55 °C

Availability: low stock

Detailed Description
Specifications

Omron K3HB-V Series Digital Panel Multi-Function Meter, 45mm Cutout Height, 5 Digit Display - K3HB-VLC 24 VAC/DC

This digital panel multi-function meter is a versatile instrument designed for precise measurements in various industrial applications. The device features a compact design with a cutout height of 45mm and width of 92mm, making it suitable for panel mounting. With a clear 7-segment LCD display, it can effectively measure load, pressure, torque, and weight, catering to diverse operational needs.

Features & Benefits

• Offers accurate measurements for load, pressure, torque, and weight
• Utilises a 7-segment LCD display for clear visibility
• Includes a measurement range up to 199.99mV for varied usage
• Designed for user-friendly operation with five easily readable digits

Applications

• Utilised in automation for monitoring various parameters
• Functions as a load measurement device for specific systems
• Serves as a pressure measurement meter in industrial setups
• Acts as a torque meter for mechanical
• Used as a weight measurement instrument in manufacturing processes

What type of measurements can this meter provide?

The meter can measure load, pressure, torque, and weight, making it suitable for a broad range of industrial applications.

How does the temperature tolerance affect performance?

The device operates effectively between -10°C to +55°C, ensuring reliable performance in diverse environmental conditions.

What is the significance of the 7-segment LCD display?

The 7-segment LCD display enables easy reading of measurements, ensuring that users can quickly and accurately interpret data in various settings.

What is the supply voltage range required for operation?

The operating voltage ranges from 20.4 to 26.4V AC, making it versatile for different wiring scenarios.

Omron K3HB Series

This new range of Process Panel Meters replaces the K3N Series. K3HB series consists of process, temperature, weighing and linear sensor indicators. These indicators with analogue inputs or pulse inputs feature a clear and easy-to-use colour-change display and all have IP66 housing. Extra functionality can be added using option boards (3 maximum).

Dimensions: 101.2 x 112 x 48 mm. Panel cut-out: 92 x 45 mm

Brand	Omron
Properties Measured	Current, Voltage
Display Type	LCD
Cutout Height	45mm
Cutout Width	92mm
Depth	100mm
Minimum Temperature	-10°C
Maximum Temperature	+55°C
