OMRON K8AK-AS1 100-240VAC | Current Monitoring Relay | 2 to 500 mA, 1 Phase, SPDT

Name: OMRON K8AK-AS1 100-240VAC | Current Monitoring Relay | 2 to 500 mA, 1 Phase, SPDT
Brand: OMRON
SKU: K8AK-AS1 100-240VAC
Availability: InStock

Part Number : K8AK-AS1 100-240VAC

OMRON K8AK-AS1 100-240VAC single-phase current monitoring relay: current ranges of 2 to 20 mA, 10 to 100 mA and 50 to 500 mA, plus overcurrent and undercurrent detection. This unit switches an SPDT output and mounts on DIN rail in a 22.5 mm wide housing. Per the product description, it handles AC or DC input. The description lists 100-240 VAC for this version.

Current ranges: 2 to 20 mA, 10 to 100 mA, 50 to 500 mA
Detection: Overcurrent, undercurrent
Contacts: SPDT
Terminals: Screw
Operating temperature: -20 to +60 °C
Standards: CE

Availability: low stock

Detailed Description
Specifications
Features
Downloads

Omron K8AK-AS/AW Monitoring Relays

The Omron K8AK series monitoring relays are expertly designed for accurate and reliable monitoring for industrial facilities and equipment. The K8AK-AW/AS relays are suitable for undercurrent and overcurrent monitoring, which the K8AK-AW can do simultaneously.
Manual resetting and automatically resetting can be maintained by one relay.
Startup lock and operating time can be set individually.

Omron K8AK-AS Series Monitoring Relay, 500mA Maximum Current Sensed, 2mA Minimum Current Sensed - K8AK-AS1

This monitoring relay is designed for efficient current monitoring in various applications. It features a compact design with dimensions of 100 x 22.5 x 90mm, making it suitable for DIN rail mounting. The relay operates within a broad temperature range, perfect for industrial settings that require precise electrical control.

Features & Benefits

• Integrates overcurrent and undercurrent protection efficiently
• Detects a wide current range from 2 mA to 500 mA
• Single-phase operation ensures effective monitoring
• Reliable screw terminal type facilitates secure connections
• Suitable for environments with temperatures from -20 °C to +60 °C

Applications

• Utilised in electrical installations for current monitoring
• Applied in control panels for automation systems
• Ideal for protecting motors against overcurrent conditions
• Used in industrial equipment requiring precise current sensing

How does this device handle different current sensitivities?

It effectively manages both overcurrent and undercurrent conditions, allowing for tailored monitoring to protect systems from current fluctuations.

What is the significance of the DIN rail mounting type?

DIN rail mounting provides a streamlined and secure installation in various control enclosures, maximising space efficiency in control panels.

What environmental conditions can it withstand?

The relay operates optimally in temperatures ranging from -20 °C to +60 °C, ensuring reliability in diverse operational settings.

What are the benefits of using screw terminals?

Screw terminals offer robust electrical connections, easy troubleshooting, and dependable long-term performance, especially in industrial environments.

What current ranges can it monitor?

This device is capable of detecting currents ranging from as low as 2 mA to a maximum of 500 mA, covering a wide spectrum of applications.

Standards

EN 60947-5-1 pollution level 2 installation category III, UL 508.
Terminal protection IP20.

Brand	Omron
Monitoring Application	Current
Electrical Phase	1
Contact Configuration	SPDT
Mounting Type	DIN Rail
Minimum Current Sensed	2mA
Maximum Current Sensed	500mA
Current Sensitivity	Overcurrent, Undercurrent
Series	K8AK-AS
Terminal Type	Screw
Length	100mm
Operating Temperature Range	+60°C
Width	22.5mm
Current Range	10 → 100 mA, 2 → 20 mA, 50 → 500mA
Standards Met	CE
Height	90mm
Dimensions	100 x 22.5 x 90mm
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-20°C

Monitoring relay 22.5mm wide, Single phase over or under current 2 to 500mA AC or DC, One SPDT, 100-240 VAC

OMRON K8AK-AS1 100-240VAC | Current Monitoring Relay | 2 to 500 mA, 1 Phase, SPDT

DOWNLOAD CATALOG

K8AK-AS1 100-240VAC Brochure - K8 Series A700000013143249
