Name: Omron MY2N DC24(S), Plug In Power Relay, 24V dc Coil, 10A Switching Current, DPDT
Brand: OMRON
SKU: MY2N DC24(S)
Availability: OutOfStock

Omron MY2N DC24(S), Plug In Power Relay, 24V dc Coil, 10A Switching Current, DPDT

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron MY2N DC24(S), Plug In Power Relay, 24V dc Coil, 10A Switching Current, DPDT

Part Number : MY2N DC24(S)

Availability: Sold out

Detailed Description
Specifications

OMRON Power Relay, 28 (L) x 21.5 (W) x 36mm (H), 636Ω Coil Resistance - MY Series - MY2N DC24(S)

When 4881960 is no longer for sale, please see RS article 2711925 for the updated version in the new range of relays from Omron.
Want to get components in your automated system up and running quickly? Put this OMRON miniature power relay on the job. At just 21.5mm wide, it fits easily into tight setups. When supplied with 24V DC, the electromagnetic coil activates the contacts to close the connected circuit. As it has a DPDT configuration, this unit can control devices in two directions, making it ideal for dual systems like intake and outtake pumps. With a response time of just 20ms, this mini marvel is primed and ready for action. Thanks to its plug-in design, popping it into your PCB is a walk in the park.

Features & Benefits

• Silver contacts resist corrosion for a long service life
• Performs reliably in temperatures between -55°C and +70°C, so it can cope with challenging environments
• Consumes just 0.9W during operation, making it an energy-efficient choice

Applications

• Manufacturing facilities
• Power generation equipment
• Telecommunications sector

What's the maximum operating frequency of this unit?

It can operate at up to 18,000 cycles per hour, so it's a high-performing pick for fast-paced applications.

How long will this power relay last?

This product can handle at least 100 million mechanical operations, making it a long-lasting device you can bank on.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Approvals

VDE; UL; CSA

Brand	Omron
Coil Voltage	24V dc
Contact Configuration	DPDT
Mounting Type	Plug In
Switching Current	10A
Number of Poles	2
Latching	No
Series	MY
Terminal Type	Plug In
Maximum Switching Voltage AC	250V ac
Maximum Switching Voltage DC	125V
Maximum Switching Current AC	10 A
Maximum Switching Current DC	10 A
Length	28mm
Coil Resistance	636Ω
Coil Power	900mW
Height	36mm
Isolation Coil To Contact	2kV
Maximum Operating Temperature	+60°C
Minimum Operating Temperature	-55°C
