Name: Omron MY4-GS-R AC48, Plug In Power Relay, 48V ac Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4-GS-R AC48
Availability: OutOfStock

Omron MY4-GS-R AC48, Plug In Power Relay, 48V ac Coil, 6A Switching Current, 4PDT

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron MY4-GS-R AC48, Plug In Power Relay, 48V ac Coil, 6A Switching Current, 4PDT

Part Number : MY4-GS-R AC48

Availability: Sold out

Detailed Description
Specifications

OMRON Power Relay, 14-Pin Connector, 20ms Response Time - MY Series - MY4-GS-R AC48

Get close circuit control in your automated setup with this power relay from OMRON. Its highly conductive silver contacts achieve efficient connections, so you get reliable energy distribution. Controlling multiple circuits at once is a breeze thanks to the component's four-pole design. By reacting to switching signals in just 20ms, it quickly opens and closes its contacts for responsive control with no delay. As the unit slots into a socket (such as 196-6153), you can count on handy plug-in connectivity for speedy system assembly.

Features & Benefits

• Current rating of 6A means it handles substantial loads
• Insulating plastic body cuts user exposure to hazardous voltages
• Solder mounting for straightforward installation
• Mechanical position indicators clearly show contact status during spot checks
• Electrical service life of up to 200,000 cycles to provide long-lasting switching

Applications

• Renewable energy production
• Machining equipment
• Semiconductor manufacturing

What's the difference between a relay and a power relay?

A relay is a component that switches a circuit based on remote switching signals. A power relay like this works in the same way while including features like overcurrent protection and extra insulation, helping to manage challenging electrical loads.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	48V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Latching	No
Series	MY
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current DC	6 A
Maximum Switching Current AC	6 A
Length	28mm
Coil Resistance	788 Ω
Coil Power	900mW
Life	300000 cycles
Isolation Coil To Contact	2kV ac
Maximum Operating Temperature	+70°C
Standards Met	CQC, CSA, IEC, UL
