Name: Omron MY4IN-GS-R AC200/220, Plug In Latching Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT
Brand: OMRON
SKU: MY4IN-GS-R AC200/220
Availability: OutOfStock

Omron MY4IN-GS-R AC200/220, Plug In Latching Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron MY4IN-GS-R AC200/220, Plug In Latching Power Relay, 220 → 240V ac Coil, 6A Switching Current, 4PDT

Part Number : MY4IN-GS-R AC200/220

Availability: Sold out

Detailed Description
Specifications

OMRON Power Relay, 240V AC Maximum Coil Voltage, 1000MΩ Insulation Resistance - MY Series - MY4IN-GS-R AC200/220

Ready to take charge of your equipment's electrical loads? Install this power relay from OMRON to your PCB. It controls the flow of electricity in your circuits so you can switch industrial devices on and off promptly. The silver nickel contacts reliably send power across in a flash while resisting corrosion, giving you a reliable connection you can bank on. Thanks to the latching lever, you can adjust this device between normal, momentary and locked states with ease. You'll find units like this used with motors, logical access controls and safety systems.

Features & Benefits

• Compact dimensions of 36 (H) x 21.5 (W) x 28mm (L) save space
• Consumes between 0.9 to 1.3W during operation, making it an energy-efficient option
• Wide operating temperature range of -55°C to +70°C for use in demanding applications
• LED indicator gives you speedy system checks

Applications

• Automotive industry
• Telecommunications networks
• Manufacturing plants

How do I mount this unit?

You can quickly install this unit by using a relay socket (196-6153), DIN rail socket (111-3063) or screw-in terminal (196-6147).

Is this power relay efficient?

Yes, as it handles up to 2400 operations per hour when using its rated load, it's suitable for fast-paced processes.

Note

This product is scheduled for discontinuation. Please refer to the attached Discontinuation notice for further details.

Brand	Omron
Coil Voltage	220 → 240V ac
Contact Configuration	4PDT
Mounting Type	Plug In
Switching Current	6A
Number of Poles	4
Series	MY
Latching	Yes
Terminal Type	Plug In
Maximum Switching Voltage AC	250V
Maximum Switching Voltage DC	220V
Maximum Switching Current AC	6 A
Maximum Switching Current DC	6 A
Length	28mm
Coil Resistance	12.95 kΩ
Coil Power	900mW
Life	300000 cycles
Standards Met	CQC, CSA, IEC, UL
Contact Material	Silver
Height	36mm
