Omron S8VK-V Series Din Rail Power Supply, 24V Output Voltage, 20A Current - S8VK-X48024A-EIP

This DIN Rail Power Supply is a reliable solution for various industrial applications. It features a compact design with dimensions of 60 x 119.3 x 125 mm, making it suitable for DIN Rail mounting. Offering an output voltage of 24V DC and a power rating of 480W, it efficiently converts AC to DC with high adaptability to different voltage inputs.

Features & Benefits

• High efficiency rating of 94% reduces energy costs
• Overvoltage and short circuit protection enhances safety
• Wide input voltage range from 100 to 240V AC
• Output voltage adjustable between 21.6 to 28V

Applications

• Used for powering automation equipment in industrial settings
• Ideal for electronic devices requiring stable DC voltage
• Utilised in control panels and machinery requiring high efficiency
• Suitable for various electrical and mechanical requiring compact power supply solutions

What is the expected lifespan of this power supply?

This power supply has a mean time between failures (MTBF) rated at 90,000 hours, indicating a long operational life under normal conditions.

How does this power supply maintain output stability under varying loads?

With a load regulation of 1.5%, it ensures consistent output voltage, accommodating fluctuations without compromising performance.

What safety features does this model include for protecting connected devices?

It includes overvoltage and short circuit protection, which safeguards connected equipment from potential damage during abnormal conditions.

Can this unit operate in extreme temperatures?

Yes, it operates effectively in temperatures ranging from -40°C to +70°C, making it suitable for harsh environments.

Standards

Harmonic current emissions EN 61000-3-2, EN 61204 -3 Class B, EN 55011 Class B, UL 508, ANSI/ISA 12.12.01 CSA C22.2 No. 107.1, CSA C22.2 No. 213 (cUL), UL 60950-1, UL 62368-1 OVC II, CSA C22.2 No. 60950-1, No. 62368-1 (cUR) OVC II,EN 50178 OVC III OVC II, EN 60950-1, EN 62368-1 OVC II, Pol2, EAC, RCM (EN61000-6-4), Korea Radio Waves Act (Law No. 10564), PELV, EN/IEC 61558-2-16. SEMI F47-0706.

Brand	Omron
Series	S8VK-V
Type	Switched Mode
Electrical Phase	1
AC or DC Input Voltage	ac
Number of Outputs	1
Input Voltage	100 → 240V ac
AC or DC Output Voltage	dc
Output Voltage	24V dc
Output Current	20A
Dimensions	60 x 119.3 x 124.6mm
Width	60mm
Depth	119mm
Height	125mm
Efficiency	94%
Minimum Temperature	-40°C
Standards Met	CE, cULus, EAC, EN 61000-3-2, EN 61204-3, EN/IEC 60529, EN/IEC 61558-2-16, TUV, UL
Maximum Temperature	+70°C
Ripple And Noise	130mV Pk-Pk
MTBF	90000h

Omron S8VK-X48024A-EIP, S8VK-V Switched Mode DIN Rail Power Supply, 100 → 240V ac ac Input, 24V dc dc Output, 20A Output, 480W

DOWNLOAD CATALOG

S8VK-X48024A-EIP Brochure - Switching Power Supply S8VK-W S8VK-S A700000013470286
