Omron XS5W-T421-DM2-K, Straight Male 4 way M12 to Straight Male 4 way M12 Sensor Actuator Cable, 2m

Client Protection

Dedicated Support

Client Protection

Dedicated Support

Omron XS5W-T421-DM2-K, Straight Male 4 way M12 to Straight Male 4 way M12 Sensor Actuator Cable, 2m

Name: Omron XS5W-T421-DM2-K, Straight Male 4 way M12 to Straight Male 4 way M12 Sensor Actuator Cable, 2m
Brand: OMRON
SKU: XS5W-T421-DM2-K
Availability: OutOfStock

Part Number : XS5W-T421-DM2-K

Availability: Sold out

Detailed Description
Specifications
Downloads

XS5W Series Cat5e Industrial RJ45 to M12 4 Pin Cable Assemblies

From Omron, a series of industrial grade PVC Cat5e cable assemblies. The patch cables have standard RJ45 plug going to M12 4-pin Smart Click plug and are ideally suited to out of cabinet applications. Constructed from 6.5 mm OD 4-pair 22 AWG cable featuring double shielding with overall braiding and individual foil shields on each pair to reduce EMC interference. Available with a light blue PVC jacket in various lengths.

Features and benefits

Cat5e Performance
PVC cable
Overall braiding
Individual foil shielding on each pair
Reduces EMC interference
Ideal for out of panel applications
IP20

Applications

PCs
Network equipment
Servers
Data centres
Industrial automation
Robotics

Omron Electronics Range

Brand	Omron
Series	XS5W
Cross Sectional Area	0.34 mm²
Number of Cores	4
Sheath Colour	Grey
Length	2m
Sheath Material	PUR
Connector 1 Number of Contacts	4
Connector 1	M12
Connector 1 Orientation	Straight
Connector 1 Gender	Male
Connector 2	M12
Connector 2 Orientation	Straight
Connector 2 Number of Contacts	4
Connector 2 Gender	Male
Connector 2 Housing Gender	Male
Shielded/Unshielded	Shielded
Voltage Rating	30 V
Current Rating	3 A
IP Rating	IP20, IP67
