Pressure Sensor ifm electronic PN7007
The PN7007 electronic pressure sensor from ifm has a 4-digit alphanumeric display, two programmable switching outputs or one switching output and one diagnostic output. The pressure sensor measures pressure ranges from 0-1 bar and convinces with a high overload protection thanks to ceramic measuring cells. Thanks to the high protection rating IP65 the PN7007 pressure sensor is very robust. The robustness and the long life of the pressure sensor ensure reliable operation. The PN7007 electronic pressure sensor from ifm has a 4-digit alphanumeric display, two programmable switching outputs or one switching output and one diagnostic output.
- Specifications
- Features
- Downloads
| Ambient temperature | -20 °C to 80 °C |
| Current consumption [mA] | <35 |
| Electrical design | PNP/NPN |
| Operating voltage [V] | 18-36 DC V |
| Output function | normally open / closed; (configurable) |
| Protection class | III |
| Reverse polarity protection | yes |
| Short-circuit protection | yes |
| Switching frequency DC [Hz] | <170 Hz |
| System | gold-plated contacts |
- Two programmable switching outputs
- With long-term stability thanks to high overload protection
- Lifespan of more than 100 million pressure cycles
- Clearly visible 4-digit LED display
- Country-specific pressure units selectable
