Ralston LC20-GC2M-00-B1 | Digital Pressure Gauge | +/- 15 psi / 1 bar / 100 kPa | 1/4" Male NPT bottom connection | Bluetooth radio
The LC20 is a sturdy instrument that measures pressure and shows the results on a sizable screen with backlighting. The LC20 can switch between 15 different engineering units, create custom engineering units, and display high and low pressure readings on the LCD. Calibration, testing, and real-time pressure viewing are all possible with the integrated PC FieldLab Desktop program.

Free UAE shipping available
- Specifications
- Features
- Downloads
Battery Life | 1000 Hours |
Battery type | AA Alkaline (IEC-LR6) |
Connection | End 1 Connector 1/4" Male NPT (ASME B1.20.1) |
Connection | Process Connection Location Bottom mount |
Display | 2.4 in / 61 mm segmented LCD Display |
Height | 4.1 in / 11 cm |
Length | 1.75 in / 45 mm |
Material | ABS / Polycarbonate Blend, Powder Coated Aluminum |
Maximum operating temperature | 122 °F / 50 °C |
Minimum Operating Temperature | -4 °F / -20 °C |
Protection | IP67 (1 meter water submersion for 30 minutes) |
Technical Data | Sensor A Bottom Max Vacuum 30 InHg / 101.6 kPa Measurement Type Gauge Pressure, Gauge Vacuum 7/8 In / 23 mm Sensor Type Pressure Sensor Max Storage Temperature 167 °F / 75 °C Min Storage Temperature -40 °F / -40 °C Max Pressure 15 PSI / 1 bar / 100 kPa Max Operating Temperature 122 °F / 50 °C Min Operating Temperature -4 °F / -20 °C Process Connection 1/4" Male NPT |
Weight | 12.6 oz / 355 grams |
Width | 3.4 in / 87 mm |
Included Items
USB-A to Micro USB-B cable, 2m long
D-000040
Tilt Antenna for LC20 and LC30 devices with Bluetooth Radios
D-000041
