TTi QL355T SII | Linear Regulated Precision Power Supply | Dual QL355 plus 1-6V/3A
The QL Series II is TTi's most recent and high-performance linear regulated power supply series. There are single and triple output models available. Each model is available with or without a digital remote control interface. Each primary output delivers over 100 watts of power, while dual range capability allows for larger currents at lower voltages.
On T models, new features include an improved auxiliary output with completely changeable voltage and increased current capabilities, and on all P models, an LXI-compliant LAN interface.
- Specifications
- Features
- Downloads
| Brand | Aim-TTi |
| Series | QL Series II |
| Model Number | QL355T SII |
| Number of Outputs | 3 |
| Output Voltage | 0 → 35 V, 0 → 15 V, 1 → 6V |
| Supply Voltage | 115 V ac, 230V ac |
| Output Current | 3 A, 0 → 3 A, 0 → 5A |
| Power Rating | 228W |
| Number of Displays | 4 |
| Bench Power Supply Type | Precision DC Power Supply |
| Type | Linear |
| Digital/Analogue | Digital |
| Input Connector | IEC 320 |
| Output Connector | Binding Post Terminal |
| Minimum Temperature | +5°C |
| Maximum Temperature | +40°C |
Multiple voltage/current ranges for increased flexibility
Multiple non-volatile memories for power supply set-ups
Switchable remote sense provides perfect load regulation
Comprehensive protection including OVP and OCP trips
Compact bench footprint; modular width for rack mounting
2x(35V/3A) & 1x(6V/3A) or 1x(15V/5A) & 1x(6V/3A)
TTi QL355T SII Dual QL355 plus 1-6V/3A Linear Regulated Precision Power Supply
Advanced dc power supply range, single or triple output
Very high precision, very low noise, excellent dynamics
Advanced user interface with numeric and rotary control
