Winters DPG208 | DIGITAL PRESSURE GAUGE | Range -15/0/200 psi
Digital gauges are practical tools for determining pressure values because they give quick, visible results. Look no farther if you're seeking for digital gauges! Among the best-performing digital gauges available is our DPG Digital Pressure Gauge. Perfect for general purpose installations and test measurement in both commercial and industrial settings
- Specifications
- Features
- Downloads
| Accuracy | +/-1% (+/-0.5% optional for gauges up to 10,000 psi) |
| Battery Life | 2 yrs (auto shut-off mode) |
| Case Size | 2.5" (63mm) |
| Casing material | : ABS |
| Connection | 1/4� NPT 304SS |
| Dial Size | 2.5� (63mm) |
| Display | LCD 2� x 3/4� (48mm x 16mm) |
| Enclosure Rating | IP60 |
| Measuring Units | psi, mH2O, mmHg, mbar, kPa ranges ¢°¤ 100 psi psi, bar, kgf/cm2, MPa, atm ranges ¢°¥ 160 psi |
| Operating Life | 1 million cycles |
| Operating Temperature | 14oF to 122oF (-10oC to 50oC) |
| Power Mode | Auto or manual shut-off |
| Power Supply | 2 x AAA battery (1.5V) |
| Range | -15/0/200 psi |
| Response Time | ¢°¤ 3 Hz display refresh rate |
| Rubber Boot | Silicone rubber |
| Sensor Type | 316L welded, Piezo |
| Storage Temperature | -4oF to 167oF (-20oC to 75oC) |
- straightforward two-button operation.
- feature that resets to zero.
- Pressing the on/off button activates the backlight.
- The option to keep the display on all the time.
- Option for continuous peak pressure indication.
- 316L diaphragm seal, welded.
- Standard equipment is a rubber boot.
- Compliant with ASME B40.100.
- RoHS compliant.
- Precision within ±1% (±0.5% optional for gauges up to 10,000 psi).
