AVENTICS 0822393602 Pneumatic Compact Cylinder - , 32mm Bore, 15mm Stroke, KPZ Series, Double Acting

Name: AVENTICS 0822393602 Pneumatic Compact Cylinder - , 32mm Bore, 15mm Stroke, KPZ Series, Double Acting
Brand: Aventics
SKU: 0822393602
Availability: OutOfStock

Part Number : 0822393602

Availability: Sold out

Detailed Description
Specifications

The Aventics KPZ compact cylinder is engineered for versatility and high performance in various industrial applications. Recognised for its compact design, this series is suitable for tight spaces while delivering robust operational capabilities. The cylinder is crafted from high-quality materials, ensuring durability and reliability under challenging conditions. With options for double-acting functionality, elastic cushioning, and an internal thread piston rod, it provides superior control and efficiency. Whether you’re looking to automate machinery or enhance system responsiveness, the KPZ compact cylinder stands as a dependable solution tailored to meet your specific automation needs. Additionally, it accommodates a broad range of ambient and medium temperatures, promoting optimal performance across diverse environments.

Dynamic sealing ensures minimal leakage and maximum efficiency
The robust aluminium construction offers increased strength and reduced weight
Magnetic piston variant enhances positioning accuracy for repeatability
Elastic cushioning extends service life and reduces wear during operation
ATEX certification option provides reliability in explosive atmospheres
Wide range of sizing options for tailored applications
Easy installation with standard port sizes for simplified integration
Low minimum working pressure enhances energy efficiency

Brand	AVENTICS
Manufacturer Series	KPZ
Model Number p	0822393602
Stroke	15mm
Bore	32mm
Action	Double
Port Connection	G 1/8
Pneumatic Connection	G 1/8
Piston Rod Thread Gender	Female
Cushioning Type	Elastic
Maximum Operating Pressure	10 bar
Maximum Operating Temperature	+80°C
Minimum Operating Temperature	-20°C
