AVENTICS R412010721 Pressure Sensor 80bar, 12 → 125V dc, IP65 16 bar

Name: AVENTICS R412010721 Pressure Sensor 80bar, 12 → 125V dc, IP65 16 bar
Brand: Aventics
SKU: R412010721
Availability: OutOfStock

Part Number : R412010721

Availability: Sold out

Detailed Description
Specifications
Downloads

The Aventics Pressure Switches is a compact pressure switch for measuring compressed air and hydraulic oil. It offers selectable pressure ranges from -0.9 to 16 bar, with available options of -0.9 to 0 bar, -0.9 to 1 bar, -0.9 to 3 bar, or 0.2 to 16 bar. The series features a robust housing, various process connections, and an ATEX version.

Housing material Aluminum
Seal material Acrylonitrile butadiene rubber
Material electrical connection Brass

Brand	AVENTICS
Suitable Media	Air, Oil
Maximum Operating Pressure	16 bar
Minimum Operating Pressure	0.2bar
Proof Pressure	80bar
Supply Voltage	12 → 125V dc
IP Rating	IP65
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+80°C
