AVENTICS R480637838 ISO Standard Cylinder - R480637840, 16mm Bore, 20mm Stroke, SSI Series, Double Acting

Name: AVENTICS R480637838 ISO Standard Cylinder - R480637840, 16mm Bore, 20mm Stroke, SSI Series, Double Acting
Brand: Aventics
SKU: R480637838
Availability: InStock

Part Number : R480637838

Availability: low stock

Detailed Description
Specifications
Downloads

The Aventics SSI Series Short stroke cylinder ideal for simple assembly and clamping movements, tight installation space and short strokes. Available as piston rod, single or double acting cylinders, with a hollow piston rod, as a non rotating version with a front plate, or an especially short version without a magnet.

Mount on moving machine parts possible thanks to their low weight
Intelligent connection concept

Brand	AVENTICS
Manufacturer Series	SSI
Model Number p	R480637840
Bore	16mm
Action	Double
Stroke	20mm
Pneumatic Connection	M5
Port Connection	M5
Piston Rod Thread Gender	Female
Cushioning Type	Elastic
Maximum Operating Pressure	10 bar
ISO Standard	ISO 15524
Stroke Interval Weight	0.017 @ 10 mm kg/mm
Test Weight	0.039 kg
Minimum Operating Temperature	-20°C
Maximum Operating Temperature	+80°C

AVENTICS R480637838 ISO Standard Cylinder - R480637840, 16mm Bore, 20mm Stroke, SSI Series, Double Acting

DOWNLOAD CATALOG

R480637838 Datasheet - R480637838 A700000012584496
