Dwyer RMB-54D | Rate-Master Flowmeter | 20-200 SCFH (10-95 LPM) Air, 5" Scale, No Valve
Part Number : RMB-54D
Built without a valve, the Dwyer RMB-54D Rate-Master flowmeter gives a direct reading of 20-200 SCFH (10-95 LPM) air across a 5" (127 mm) scale. Use the RMB-54D for general-purpose gas or liquid flow monitoring, either surface mounted or set into a panel.
- Range 20-200 SCFH (10-95 LPM) air on the 5" (127 mm) scale, no valve fitted
- 3% accuracy and 1/4" female NPT process connections on the RMB-54D
- RMB-54D rated to 100 psi (6.9 bar) and 130°F (54°C) maximum operating conditions
- Wetted parts of the RMB-54D: polycarbonate body, Neoprene/Buna-N O-rings, stainless steel metal parts
- RMB-54D body swaps within its 5" scale size for cleaning or a range change, leaving pipework in place
- Weighs 13 oz (368.5 g); the RMB-54D meets RoHS II (EU Directive 2011/65/EU)
Free UAE shipping available
For pricing, please contact our experts.
