Mark-10 M5-012 | Series 5 Digital Force Gauge | 0.12 lbF / 0.5 N
Part Number : M5-012
Mark-10 part number M5-012 is the 0.12 lbF (0.5 N) model in the Series 5 digital force gauge line, used for production and laboratory force testing. It is the lowest-capacity model in the Series 5 range, which spans from 0.12 to 2,000 lbF, or 0.5 N to 10 kN. The M5-012 measures in both tension and compression and samples at 7,000 Hz.
Key features
- Capacity: 0.12 lbF / 0.5 N in tension and compression
- High-speed 7,000 Hz sampling, 500 Hz output rate
- External trigger input for switch contact tests or freezing the display
- Real-time load bar graph showing set points
- Five selectable measurement units
- Key and calibration access can be password protected
For pricing, please contact our experts.
