Mitutoyo 395-353-30 Digital Tube Micrometer, Spherical Anvil Inch/Metric, 2-3", IP65
This Digimatic Tube Micrometer allows you to measure curved
surfaces such as the wall thickness of tubes, bearings and rings.
With radius of anvil/spindle faces: carbide R=4 mm.
- Specifications
- Features
- Downloads
| Analog/Digital | Digital |
| Battery Life | Approx. 2,4 years |
| Data Output | Yes |
| Delivered | Including box, setting standard |
| Digital step | 0.00005 |
| Flatness | 0.000012 |
| Inch-Metric | Inch/Metric |
| Mass (main unit) | 470 g |
| Measuring spindle | With spindle lock, ƒ ̧6.35 mm, spindle pitch 0.635 mm |
| Measuring surfaces | Carbide-tipped, micro-lap finish |
| Scale | Thimble and sleeve satin chrome finish, ƒ ̧18 mm |
| ZERO/ABS | Yes |
This Digimatic Tube Micrometer allows you to measure curved
surfaces such as the wall thickness of tubes, bearings and rings.
With radius of anvil/spindle faces: carbide R=4 mm.
