Mitutoyo 570-412 | Digital ABS Height Gauge | Series 570 | Digital Step 0.0005 mm | Accuracy ±0.0015 mm | Range 0 to 12 Inch
The Mitutoyo 570-412 Digital ABS Height Gauge from Series 570 is designed for high-precision measurements in both industrial and laboratory settings. It features ABSOLUTE (ABS) encoder technology, which retains the origin point even after the gauge is powered off, eliminating the need for frequent zero-setting. With a measuring range of 0 to 12 inches and a fine digital resolution of 0.0005 inch, it provides excellent accuracy and repeatability. The gauge boasts an accuracy of ±0.0015 inch, making it suitable for critical measurement tasks. Built for durability and ease of use, it offers a smooth sliding operation and a clear digital display. This height gauge is a reliable tool for professionals who demand precision and efficiency.

Free UAE shipping available
- Specifications
- Features
- Downloads
Analog/Digital | Digital |
Battery Life | Approx. 5 years under normal use |
Data hold function | Yes |
Digital step | 0.0005 Inch or 0.01 mm |
Display | LCD, character height 12 mm |
Inch-Metric | Inch/Metric |
Max. permissible error | E MPE: +/-0.0015 Inch or +/-0.03 mm |
Max. Response Speed | Unlimited |
Model Number | HDS-12"CX |
ON/OFF | Yes |
Power Supply | 1 battery SR-44 |
Range | 0 - 12 Inch |
Scale | ABSOLUTE capacitance type linear encoder |
Series | 570 |
Type | Digital ABS Height Gauge |
- Measurement Range: 0 to 12 inches
- Resolution: 0.0005 inch (0.01 mm) for high-precision readings
- Accuracy: ±0.0015 inch, suitable for tight tolerance requirements
- ABSOLUTE (ABS) Encoder: Retains origin point, no need to reset zero
- Digital Display: Easy-to-read LCD for quick and clear measurements
- Robust Construction: Durable design for long-lasting performance in shop or lab environments
